Lenovo Thinkpad E14 Ryzen Benchmarks

Below are the results from the benchmarks I ran.

Benchmarks & Performance (Page 2)

YABS – Yet Another Benchmarking Script

wget -qO- yabs.sh | bash -s -- -i

Tuesday 11 January 2022 06:54:38 AM IST

Basic System Information:
---------------------------------
Processor  : AMD Ryzen 5 5600U with Radeon Graphics
CPU cores  : 12 @ 2300.000 MHz
AES-NI     : ✔ Enabled
VM-x/AMD-V : ✔ Enabled
RAM        : 6.7 GiB
Swap       : 0.0 KiB
Disk       : 138.0 GiB

fio Disk Speed Tests (Mixed R/W 50/50):
---------------------------------
Block Size | 4k            (IOPS) | 64k           (IOPS)
  ------   | ---            ----  | ----           ----
Read       | 475.78 MB/s (118.9k) | 619.38 MB/s   (9.6k)
Write      | 477.03 MB/s (119.2k) | 622.64 MB/s   (9.7k)
Total      | 952.81 MB/s (238.2k) | 1.24 GB/s    (19.4k)
           |                      |
Block Size | 512k          (IOPS) | 1m            (IOPS)
  ------   | ---            ----  | ----           ----
Read       | 780.32 MB/s   (1.5k) | 911.75 MB/s    (890)
Write      | 821.78 MB/s   (1.6k) | 972.47 MB/s    (949)
Total      | 1.60 GB/s     (3.1k) | 1.88 GB/s     (1.8k)

Geekbench 5 Benchmark Test:
---------------------------------
Test            | Value
                |
Single Core     | 1161
Multi Core      | 4065
Full Test       | https://browser.geekbench.com/v5/cpu/12098952

Thermal Performance

Max CPU temperature I noticed went up to 80 Deg C while running batch process of converting images (heic images to jpg), total ~ 10,000 images. On running the ‘sensors’ command in terminal, upon fresh boot, I got 46 degrees C. You can click below to see the results from running the “sensors” command.

$ sensors
thinkpad-isa-0000
Adapter: ISA adapter
fan1:        2200 RPM
CPU:          +46.0°C
GPU:           +0.0°C
temp3:         +0.0°C
temp4:         +0.0°C
temp5:         +0.0°C
temp6:         +0.0°C
temp7:         +0.0°C
temp8:         +0.0°C

nvme-pci-0100
Adapter: PCI adapter
Composite:    +29.9°C  (low  = -273.1°C, high = +75.8°C)
                       (crit = +86.8°C)
Sensor 1:     +29.9°C  (low  = -273.1°C, high = +65261.8°C)

amdgpu-pci-0400
Adapter: PCI adapter
vddgfx:      662.00 mV
vddnb:       693.00 mV
edge:         +44.0°C
power1:        0.00 W

k10temp-pci-00c3
Adapter: PCI adapter
Tctl:         +46.9°C

BAT0-acpi-0
Adapter: ACPI interface
in0:          12.22 V

Benchy- Thinkpad

wget -qO- https://raw.githubusercontent.com/L1so/benchy/main/benchy | sh -s -- -n
# # # # # # # # # # # # # # # # # # # # #
#             Benchy v2.0               #
#    https://github.com/L1so/benchy     #
# # # # # # # # # # # # # # # # # # # # #
#        24 Jul 2022 16:00 IST          #
# # # # # # # # # # # # # # # # # # # # #

Server Insight                                  Hardware Information
---------------------                           ---------------------
OS         : Linux Mint 21                      Model       : AMD Ryzen 5 5600U with Radeon Graphics
Location   : India                              Core        : 12 @ 3413.18 MHz
Kernel     : 5.15.0-41-generic                  AES-NI      : ✔ Enabled
Uptime     : 4 days, 1 hrs, 29 mins, 17 secs    VM-x/AMD-V  : ✔ Enabled
Virt       : none                               Swap        : 3.7 GiB

Disk & Memory Usage                             Network Data
---------------------                           ---------------------
Disk       : 23.3 GiB                           ASN         : AS134674
Disk Usage : 9.2 GiB (42% Used)                 ISP         : TATA PLAY BROADBAND PRIVATE LIMITED
Mem        : 22.3 GiB                           IPv4        : ✔ Enabled
Mem Usage  : 6.1 GiB (27% Used)                 IPv6        : ✔ Enabled

Disk Performance Check (ext4 on /dev/nvme0n1p5)
+---------------------------------------------------------------------------+
| Size | Read        | Write       | Total       |       IOPS (R,W,T)       |
+===========================================================================+
| 4k   | 438.99 MB/s | 440.15 MB/s | 879.15 MB/s | 112.4k | 112.7k | 225.1k |
| 64k  | 612.11 MB/s | 615.33 MB/s | 1.19 GB/s   | 9.8k   | 9.8k   | 19.6k  |
| 512k | 791.98 MB/s | 834.06 MB/s | 1.58 GB/s   | 1.6k   | 1.7k   | 3.2k   |
| 1m   | 886.80 MB/s | 945.86 MB/s | 1.78 GB/s   | 0.9k   | 0.9k   | 1.8k   |
+---------------------------------------------------------------------------+
Disk Performance Check (ext4 on /dev/nvme1n1p4)
+---------------------------------------------------------------------------+
| Size | Read        | Write       | Total       |       IOPS (R,W,T)       |
+===========================================================================+
| 4k   | 457.15 MB/s | 458.35 MB/s | 915.51 MB/s | 117.0k | 117.3k | 234.4k |
| 64k  | 1.14 GB/s   | 1.15 GB/s   | 2.29 GB/s   | 18.8k  | 18.9k  | 37.7k  |
| 512k | 1.23 GB/s   | 1.30 GB/s   | 2.53 GB/s   | 2.5k   | 2.7k   | 5.2k   |
| 1m   | 1.28 GB/s   | 1.36 GB/s   | 2.65 GB/s   | 1.3k   | 1.4k   | 2.7k   |
+---------------------------------------------------------------------------+

+-----------------------------------------------+
| Geekbench 5.4.4 Tryout for Linux x86 (64-bit) |
+===============================================+
| Single Core        | 1373                     |
| Multi Core         | 4715                     |
+-----------------------------------------------+
| https://browser.geekbench.com/v5/cpu/16207037 |
+-----------------------------------------------+
| Benchy time spent  | 3 Minutes 8 Seconds      |
+-----------------------------------------------+
